TP-Link MC100CM User Manual

4
¾ Connectors: RJ-45, SC.
¾ Network Cables: Cat.5 Twisted-Pair (below abbreviated as
TP), 9/125um Single-mode fiber and 50/125, 62.5/125um
Multi-mode fiber.
Model NO. Interface
Transmission
Distance
Transmission
Media
Output Center
Wavelength
MC100CM RJ45--SC 2km
Multi-mode
Fiber, TP
850nm
MC110CS RJ45--SC 20km
Single-mode
Fiber, TP
1310nm
MC111CS RJ45--SC 20km
Single-mode
Fiber, TP
1550nmTX
1310nmRX
MC112CS RJ45--SC 20km
Single-mode
Fiber, TP
1310nmTX
1550nmRX
1.5 Appearance Indication
1.5.1 LED Indicators
The converter has LED indicators which can provide a real-time
report. When you take a look at these indicators, you will know what’s
happening on your network. For details, please refer to the table as
shown below.

TP-Link MC100CM Specifications

General

Fiber optic connector	SC
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	1310 nm
Maximum transfer distance	2000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Internal	No
Certification	FCC, CE
Product color	Black
LED indicators	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Ethernet interface type	Gigabit Ethernet
Maximum data transfer rate	1000 Mbit/s
Fiber ethernet cabling technology	100BASE-FX
Power consumption (max)	2.5 W
Package depth	204 mm
Package width	165 mm
Package height	65 mm
Package weight	380 g

Weight and Dimensions

Depth	73 mm
Width	94.5 mm
Height	27 mm
