TP-Link MC111CS User Manual

Name
Status
Indication
PWR
On
Power on.
Off
Power off.
LFP
On
The Link Fault Pass Through function enable.
Off
The Link Fault Pass Through function disable.
FX
Link/Act
On
There’s a valid link.
Flashing
The converter is receiving or transmitting
data from the fiber optic connector.
Off
There’s no valid link.
TP
SPD
On
The TP port is connected to 100Base-Tx
Off
The TP port is connected to 10Base-Tx
device or no connection.
FDX/Col
On
The TP port is operating in Full-Duplex.
d
Flashing There’s a collision.
Off The TP port is operating in Half-Duplex mode.
Link/Act
On
There’s a valid link.
Flashing
The converter is receiving or transmitting
data from the TP port.
Off There’s no connection on the TP port.
5

TP-Link MC111CS Specifications

Operating Environment

operation temperature	0˚C to 40˚C (32˚F to 104˚F)
storage temperature	-40˚C to 70˚C (-40˚F to 158˚F)
operation humidity	10% to 90% RH non-condensing

Connectivity

connector	1 SC fiber optic; 1 RJ45 jack
10BASE-T cable type	2-pair UTP/STP of Cat. 3 or above (≤100m)
100BASE-Tx cable type	2-pair UTP/STP of Cat. 5 or above (≤100m)

Power

external power adapter voltage	9V
external power adapter current	0.6A
