03 Appearance
LED Indication
USB
For USB Modem:
Flashing: A modem is connected and it is initializing.
On: The modem is loaded.
Off: No modem is inserted, or it is corrupted or incompatible.
For USB Storage:
On: A USB storage device is inserted and identified.
Off: No USB storage device is inserted, or it is corrupted or incompatible.
SFP+ (Port 1-2)
Green On: Running at 10 Gbps, but no activity.
Green Flashing: Running at 10 Gbps and transmitting or receiving data.
Yellow On: Running at 1000 Mbps, but no activity.
Yellow Flashing: Running at 1000 Mbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
SFP (Port 3)
On: Running at 1000 Mbps, but no activity.
Flashing: Running at 1000 Mbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
RJ45 (Port
4-11)
Green On: Running at 1000 Mbps, but no activity.
Green Flashing: Running at 1000 Mbps and transmitting or receiving data.
Yellow On: Running at 100/10 Mbps, but no activity.
Yellow Flashing: Running at 100/10 Mbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
*PWR1 is the primary power supply and it takes priority over PWR2.
**When both PWR1 and PWR2 work properly and the router is powered by PWR1, it takes 10-20 seconds
for the LED PWR2 (yellow) to go out.
Interface Description
USB1 (LTE) USB 3.0 port for USB modem and USB storage device.
Reset
Press and hold the button for 5 seconds, the SYS LED will flash quickly, indicating the
device is being reset to its factory default settings.
USB2 USB 3.0 port for USB storage device.
Console Connect with a computer for monitoring and configuring the router.
SFP+ WAN
(Port 1)
10G SFP+ WAN port.
SFP+ WAN/LAN
(Port 2)
10G SFP+ WAN/LAN port connecting to an SFP+ module.
By default, it is a LAN port.
You can configure it to a WAN port on the management page.
SFP WAN/LAN
(Port 3)
Gigabit SFP WAN/LAN port connecting to an SFP module.
By default, it is a LAN port.
You can configure it to a WAN port on the management page.
