4
Chapter 1
Get to Know Your Powerline Adapter
Name Status Indication
Ethernet
On The Ethernet port is connected.
Off The Ethernet port is not connected.
*Five minutes after the device connected to the powerline adapter is turned off or
inactive, the powerline adapter will automatically switch to Power-Saving Mode.
1. 2. 2. Physical Interface
Power Plug
Gigabit Ethernet
Pair Button
Integrated Electrical Socket
Integrated Electrical Socket
Used as an electrical outlet expansion for power strip or household appliances. It can
remove some electrical noise that might affect powerline performance.
Power Plug
The powerline adapter has a Plug that can be connected to a power socket.
Pair Button
Press and hold the button for 1 second to join a powerline network. Go to Secure Your
Powerline Network by Pairing for more information.
Press and hold for more than 6 seconds to reset the powerline adapter.
Ethernet Port
Connect the Ethernet port to your wired devices, such as a computer, a router or a
game console, via an Ethernet cable.
