TP-Link RE580D User Manual

Basic Requirements
 Place your extender in a well-ventilated place far from direct sunlight,
any heater or heating vent.
 Leave at least 2 inches (5cm) space around the device for heat
dissipation.
 Turn off your extender and unplug the power adapter in a lighting storm
to avoid damage.
 Use Web browser, such as Microsoft Internet Explorer 5.0 or above,
Netscape Navigator 6.0 or above.
 Operating temperature of the extender should be 0℃~40℃ (32℉
~104℉).
 Operating humidity of the extender should be 10%~90%RH (Non-
condensing).
Quick Setup
Using WPS (Wi-Fi Protected Setup)
1 Power On
Plug the extender into an electrical outlet near your router, and wait until
the Power LED is lit and solid blue.
2 Connect
1) Press the WPS button on your router.
Your router should support WPS. Otherwise, please use Using
your web browser.
Connect the Extender to the Internet 5

TP-Link RE580D Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Windows operating systems supported	Yes
Certification	CE, FCC
Antennas quantity	3
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	1900 Mbit/s
Ethernet LAN (RJ-45) ports	5
Output current	2.5 A
Output voltage	12 V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 30 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	240 mm
Package width	340 mm
Package height	76 mm
Sustainability certificates	RoHS
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	162 mm
Width	242 mm
Height	44 mm
