Unmanaged/Easy Smart Rackmountable Switches
Introduction
The front panel of TL-SG1016S is shown as the following figure.
Figure 1-7 Front Panel of TL-SG1016S
10/100/1000Mbps
RJ45 Port
LEDs
The front panel of TL-SG1016DE is shown as the following figure.
Figure 1-8 Front Panel of TL-SG1016DE
Reset 10/100/1000Mbps RJ45 Port
LEDs
The front panel of TL-SG1016PE is shown as the following figure.
Figure 1-9 Front Panel of TL-SG1016PE
Reset 10/100/1000Mbps RJ45 PortLEDs
The front panel of TL-SF1024 is shown as the following figure.
Figure 1-10 Front Panel of TL-SF1024
10/100Mbps
RJ45 Port
LEDs
