4
Unmanaged/Easy Smart Rackmountable Switches
Introduction
The front panel of TL-SF1024D is shown as the following figure.
Figure 1-11 Front Panel of TL-SF1024D
10/100Mbps
RJ45 Port
LEDs
The front panel of TL-SG1024 is shown as the following figure.
Figure 1-12 Front Panel of TL-SG1024
10/100/1000Mbps
RJ45 Port
LEDs
The front panel of TL-SG1024D is shown as the following figure.
Figure 1-13 Front Panel of TL-SG1024D
10/100/1000Mbps
RJ45 Port
LEDs
The front panel of TL-SG1024S is shown as the following figure.
Figure 1-14 Front Panel of TL-SG1024S
10/100/1000Mbps
RJ45 Port
LEDs
