Chapter 2 Identifying External Components
This Chapter describes the front panel and rear panel of the
Switch.
2.1 Front Panel
Figure 2-1 TL-SG1008D Switch Front Panel
The Switch’s LEDs are located on the front panel:
¾ Power LED: This indicator will light up when the Switch
powers up.
¾ LEDs (1~8): The LED indicates Link/Active status. The
corresponding LED indicator will light solid green when
connected to a network device. It flashes green when data is
being transmitted or received on the working connection.
Note:
The LEDs’ description above explains the device’s working
status after initialization.
2.2 Rear Panel
Figure 2-2 TL-SG1008D Switch Rear Panel
