TP-Link TL-WPA281 User Manual

TL-WPA281/TL-WPA271 Wireless N Powerline Extender
4
LEDs Name Status Indication
Solid The device is on.
Power LED
Off The device is off.
Solid The device is connected to a powerline network.
Off The adapter isn’t connected to any powerline network.
Powerline
LED
Blinking The device is transferring data.
Solid
The Ethernet port is connected, but there is no data being
transferred.
Off The Ethernet port isn’t connected.
Ethernet LED
Blinking The Ethernet port is transferring data.
Solid
If the LED becomes solid light for 300 seconds, this
indicates a successful WPS connection.
Off The wireless function has been disabled.
Blinking slowly
The device is waiting for client devices to connect to it by
WPS.
WiFi/WPS
LED
Blinking quickly The wireless function has been enabled.
2.3 Physical Interface
There are four physical items on this device.

TP-Link TL-WPA281 Specifications

General

Modulation	OFDM
Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
PowerLine standard	HomePlug AV
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Networking standards	IEEE 802.11b, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Built-in power socket	No
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Maximum data transfer rate	300 Mbit/s
Maximum operating distance	300 m
Ethernet LAN interface type	Fast Ethernet
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Power consumption (typical)	6 W
Certification	CE, FCC
Product color	White
LED indicators	LAN, Power, WLAN
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	40 mm
Width	58 mm
Height	105 mm
