TL-WR743ND 150Mbps Wireless AP/Client Router
- 134 -
Appendix C: Specifications
General
Standards
IEEE 802.3, 802.3u, 802.3x, 802.1x, 802.11n, 802.11b, 802.11g,
802.11e, 802.11i
Protocols TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
Ports
One 10/100M Auto-Negotiation INTERNET RJ45 port supporting
passive POE at AP Client Router mode; Four 10/100M
Auto-Negotiation LAN RJ45 ports supporting Auto MDI/MDIX
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Cabling Type
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
LEDs
（Power）, (System), (WLAN), (INTERNET),
(LAN 1-4),
(WPS)
Safety & Emissions FCC, CE
Wireless
Frequency Band 2.4~2.4835GHz
Radio Data Rate
11n：up to 150Mbps（Automatic）
11g：54/48/36/24/18/12/9/6M（Automatic）
11b：11/5.5/2/1M（Automatic）
Frequency Expansion DSSS(Direct Sequence Spread Spectrum)
Modulation DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
Security WEP/WPA/WPA2/WPA2-PSK/WPA-PSK
Sensitivity @PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER;
54M: -68dBm@10% PER
11M: -85dBm@8% PER;
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Antenna Gain 5dBi
Environmental and Physical
Operating : 0~40 (32 ~104)
Temperature.
Storage: -40~70(-40~158)
Operating: 10% - 90% RH, Non-condensing
Humidity
Storage: 5% - 95% RH, Non-condensing
