TL-WR743ND 150Mbps Wireless AP/Client Router
- 57 -
MAC Address - The physical address of the LAN ports, as seen from the LAN. The value
can't be changed.
IP Address - Enter the IP address of your Router in dotted-decimal notation (factory default:
192.168.0.1).
Subnet Mask - An address code that determines the size of the network. Normally use
255.255.255.0 as the subnet mask.
Note:
1. If you change the IP Address of LAN, you must use the new IP Address to login to the Router.
2. If the new LAN IP Address you set is not in the same subnet with the previous one, the IP
Address pool in the DHCP server will be configured automatically，while the Virtual Server and
DMZ Host will not take effect until they are re-configured.
4.7 Wireless
Figure 4-16 Wireless menu
There are five submenus under the Wireless menu (shown in Figure 4-16): Wireless Settings,
Wireless Security, Wireless MAC Filtering, Wireless Advanced and Wireless Statistics. Click
any of them, and you will be able to configure the corresponding function.
4.7.1 Wireless Settings
Choose menu “Wireless → Wireless Settings”, and then you can configure the basic settings
for the wireless network on this page.
4.7.1.1 Wireless Settings in Client Router Mode
If y
ou select Client Router mode in Figure 3-6 or Client Router mode in Figure 4-5, the Wireless
Settings p
age will display as Figure 4-17.
