TQ Display V01 - Technical Data; Display Specifications; Remote Specifications

EN – 6
2 Technical data
2.1 Display
Screen diagonal 2 inch
State of charge indication Seperate for Battery and range extender
Connectivity Bluetooth, ANT+ (Radio network standard
with low power consumption)
Protection class IP66
Dimension 74 mm x 32 mm x 12,5 mm /
2,91“ x 1,26“ x 0,49“
Weight 35 g / 1,23 oz
Operating temperature
Storage temperature
-5 °C to +40 °C / 23 °F to 104 °F
0 °C to +40 °C / 32 °F to 140 °F
Tab. 1: Technical data – Display V01
2.2 Remote
Protection class IP66
Weight with cable 25 g / 0,88 oz
Operating temperature
Storage temperature
-5 °C to +40 °C / 23 °F to 104 °F
0 °C to +40 °C / 32 °F to 104 °F
Tab. 2: Technical data – Remote
