COMBO ENCLOSURE SPECIFICATIONS
715 715x 1215 1210
Combo Enclousure Specications:-
Transducer Complement:
1 x 15’’ + Horn 1 x 15’’ + Horn 1 x 15’’ + Horn 2 x 10’’ + Horn
Maximum Output Power
450W 600W 600W 600W
Internal Speaker Power Handling:
300WRMS 500WRMS 500WRMS 400WRMS
Nominal Impedance:
4Ω 8Ω 8Ω 8Ω
Frequency Response:
40Hz – 15kHz 35Hz – 15kHz 35Hz – 15kHz 35Hz - 15kHz
Sound Pressure Level 1W, 1m
99dB 100dB 100dB 100dB
Cabinet Tuning Frequency:
42Hz 42Hz 42Hz 40Hz
Crossover Frequency (internal passive):
n/a 5kHz 5kHz 5kHz
Controls:
- Horn switch Horn switch Horn switch
Enclosure Materials & Finish
90% Poplar Ply, 10% MDF, Black vinyl covering, metal hardware
Individual Woofer Spec:-
Power rating
300W 500W 500W 200W
Sensitivity
98dB 100dB 100dB 97dB
Voice coil diameter
2 ½’’ (64mm) 3’’ (76mm) 3’’ (76mm) 2’’ (51mm)
Magnet Weight
1.4kg / 50oz 2.2kg / 77oz 2.2kg / 77oz 1.2kg / 42oz
Cone material
Kevlar® impregnated paper
Horn Type
Ceramic Tweeter Phenolic horn loaded dome tweeter
DIMENSIONS & WEIGHTS
Dimensions & Weights Width Height Depth Weight
mm inches m m inches m m inches kg lbs
715 491 19.3 623 24.5 335 13.2 28 62
715x 615 24.2 623 24.5 335 13.2 36 79
1215 615 24.2 623 24.5 335 13.2 38 83
1210 615 24.2 623 24.5 335 13.2 40 87
AH600-7 491 19.3 158 6.2 335 13.2 15 33
AH600-12 491 19.3 158 6.2 335 13.2 17 37
AH1200-12 491 19.3 158 6.2 435 17.1 22 48
