TRACE ELLIOT 715x - Technical Specifications; 7 Band vs. 12 Band Specification Comparison

Specications 7 Band 12 Band
INPUT sensitivity
HI 77.5mV RMS (-20dBu)
LO 245mV RMS (-10dBu)
INPUT impedance
HI 1MΩ
LO 100kΩ
PRE SHAPE Frequency Response +6dB @ 50 Hz. - 12dB @ 400Hz. +6dB @ 5kHz
Slope = 6dB/octave
GRAPHIC EQUALIZER +/- 15dB at 7 frequencies +/- 15dB at 12 frequencies
COMPRESSOR Single band, soft knee, with adaptive
attack and release times
Dual band, soft knee, with specically
set attack and release times per band.
EFFECTS SEND(S)
Load impedance 1KΩ or greater
Nominal Output Level -10dBV, 0.3VRMS
EFFECTS RETURN(S)
Impedance 100kΩ
Nominal input level -10dBV, 0.3VRMS
TUNER OUT level Instrument level via buffer Nominal -10dBV, 0.3VRMS
LINE OUT(S)
Load Impedance 1KΩ or greater
Level with OUTPUT LEVEL on 5 0dBu, 0.775VRMS
DI OUTPUT(S)
Load impedance 600Ω or greater
Nominal Output Level 0dBu, 0.775VRMS
EXTERNAL CONTROL 4 function footcontroller 6 function footcontroller
VALVES n/a 2 x ECC83/12AX7 Double Triode
DC lament supply
HUM & NOISE Greater than 80dB below rated power
FREQUENCY RESPONSE +/-3dB, 20Hz-25kHz
POWER AMPLIFIER
Protection Current limit protection, thermal protection, anti-clip protection
Minimum Load 4Ω, for full rated ouput power
Power Output at 8 Ω Approx 60% of rated power
SUPPLY VOLTAGE Local nominal mains voltage (230/120/100) +/- 10%
ACCESSORIES IEC lead, protective cover, footcontroller, owners manual
SPECIFICATIONS
27
