Specifications
Weight:
1.6 lb (0.73 Kg)
Dimensions (H x W x D):
1.35” (3.4cm) x 6.75” (17.1cm) x 4.10” (10.4cm)
e following nominal measurements were taken with all controls set at 12 o’clock, unless otherwise noted:
Nominal INPUT level:
PASSIVE = -1.41 dBV
ACTIVE = 4.60 dBV
Maximum INPUT level:
PASSIVE = 4.60 dBV
ACTIVE = 10.9 dBV
INPUT impedance:
PASSIVE = 500k Ohms
ACTIVE = 44k Ohms
Nominal DRY OUT level = 0.00 dBV
Nominal INST OUTPUT level = -10 dBV
INST OUTPUT impedance = 1k Ohms
Nominal LINE OUTPUT level = 1.78 dBV (+4 dBu)
LINE OUTPUT impedance = 1k Ohms
Nominal D.I. PRE level = 1.78 dBV (+4 dBu)
Nominal D.I. POST level = 1.78 dBV (+4 dBu)
EQUALISATION:
BASS = +/- 15 dB @ 117 Hz; Q = 0.91
LO-MID = +/- 15 dB @ 279 Hz; Q = 0.89
MID = +/- 15 dB @ 664 Hz; Q = 0.88
HI-MID = +/- 15 dB @ 1.73 kHz; Q = 0.74
TREBLE = +/- 15 dB @ 4.95 kHz; Q = 0.73
AUX IN level:
Nominal = 1.78 dBV (+4 dBu)
AUX IN input impedance = 10k Ohms
PHONES output level:
Minimum load impedance = 4 Ohms
Maximum output power at minimum load = 500 mW (rms)
COMPRESSION : Two-band compressor with crossover point at 333 Hz and option to place the compressor
either before or aer the EQUALISATION controls in the signal chain.
