Trackmaster TMX425 - Inverter Assembly Details

February 1, 2004 TMX425 Series Owner’s Manual B-1
D
rawings
Appendix
B
Inverter Assembly 110V Software Version 402 / 403 / 404
Item Description Part
Number
Qty
1 Inverter – Lesson 317-160-105 1
2 Inverter Signal Harness 317-160-036 1
3 Power Input Harness 317-160-069 1
4 Capacitor 317-160-035 1
5 HN - #8 – 32 Nylon 001-1763 4
6 Isolation Mount 317-160-040 4
7 Tie Wrap – 4” 317-160-075 1
