Trackmaster TMX425 - Page 38

TRACKMASTER
115V Motor Pan Assembly
Item Description Part Number Qty
1 MOTOR ASSEMBLY 317-179-001 1
2 WASHER NYLON 317-160-086 2
3 HNS 3/8-16 FLANGE 001-1399 8
4 NLN 3/8-16 001-1430 1
5 LINEAR ACTUATOR 115v 317-160-090 1
6 TRIM MINI BLACK 001-102-044 6’’
7 TIE CABLE .10 X 4.00 317-160-075 1
8 NOT PICTURED HHWHTS #8-32 X 3/8 001-1744 4
9 TRIM MINI BLACK 001-102-044 3’’
10 INVERTOR ASSEMBLY 110v 317-376-001 1
11 TRIM MINI BLACK 001-102-044 7.1’’
12 MOTOR PAN WELDMENT 317-170-001 1
13 LW #10 EXTERNAL TOOTH 001-1751 1
14 GRIP POWER CORD 317-160-012 1
15 PLATE BREAKER MOUNT 317-160-073 1
16 BREAKER 2 amp 317-160-089 2
17 BREAKER ¼ amp 317-160-024 2
18 HHWHTS #8-32 X 3/8 001-1744 2
19 POWER CORD 115v 317-160-091 1
20 TAG CORD 317-160-077 1
21 TIE CABLE .10 X 4.00 317-160-075 1
22 DECAL RS232 317-160-081 1
23 SCREW HEX JACK 3/16 X ½ 317-160-066 2
24 TIE CABLE .10 X 4.00 317-160-075 2
25 MOUNT CIRCUIT BOARD 317-160-041 2
26 PHPHTS #8-32 X ½ 001-1765 2
27 HH SCREW #10-32 X 3/8 GRN 317-160-076 1
28 HN STOVER LOCK 3/8-16 FLANGE 001-1820 4
29 TRIM MINI BLACK 001-102-044 1.6’’
30 TRIM MINI BLACK 001-102-044 1’’
31 MAIN WIRE HARNESS 317-160-042 1
32 BOARD PCB0276 317-160-014 1
33 HHCS 3/8-16 X 4.5 GR5 001-1743 1
34 HHMS #8-32 X ½ 001-1764 2
35 FILTER CE 115v 317-160-087 1
36 SWITCH 115v 317-160-088 1
37 HARNESS 9 PIN BUS SUPPORT 317-160-065 1
38 RHMS #6-32 X 3/8 001-1745 2
39 LIGHT POWER ON 317-160-010 1
40 HH SCREW #10-32 X 3/8 GRN 317-160-076 1
41 DECAL GROUND 317-160-079 1
42 HARNESS CE FILTER GROUND 317-160-070 1
43 HARNESS CE FILTER INPUT 317-160-071 1
44 HNS #8-32 FLANGE 001-1636 2
