TRACKMASTER
Frame Assembly
Item Description Part
Number
Qty
1 EXTRUSION ANTI-SKID RUBBER 317-160-055 2
2 RAIL WELDMENT LEFT HAND 317-164-001 1
3 ANTI SLIP SAFTY WALK 317-160-084 2
4
FW
∅
1/4’’
001-1439 4
5
LW
∅
1/4’’
001-1450 4
6 HHCS ¼-20 X ¾’’ GR5 001-1186 4
7 FOOT ASSEMBLY REAR 317-186-001 1
8 RAIL WELDMENT RIGHT HAND 317-163-001 1
9 MOTOR PAN ASSEMBLY 220v FULL ASSEMBLY 317-200-1-1 1
10 BRACKET WELDMENT 317-177-001 1
11
LW
∅
5/16’’
001-1451 2
12 HSHCS 5/16-18 X ¾’’ 001-1675 2
13 HHCS ¼-20 X ¾’’ GR5 001-1186 4
14
FW
∅
1/4’’
001-1439 4
15
LW
∅
1/4’’
001-1450 4
16 HHCS ¼-20 X ¾’’ GR5 001-1186 2
17
LW
∅
1/4’’
001-1450 2
18
FW
∅
1/4’’
001-1439 2
19 BELT DRIVE 317-160-026 1
20 HN ¼-20 GR5 001-1386 6
21
LW
∅
1/4’’
001-1450 6
22 HHCS ¼-20 X ¾’’ GR5 001-1186 6
23
FW
∅
1/4’’
001-1439 6
24 HHCS 5/16-18 X 6’’ GR2 001-1742 2
25
FW
∅
5/16’’
001-1440 4
26 HN 5/16-18 GR5 001-1387 4
27
LW
∅
5/16’’
001-1451 4
28 HANDRAIL MOUNT WELDMENT 317-160-006 2
29 HN ¼-20 GR5 001-1386 4
30 BRACKET LEFT HAND 317-160-046 1
31 BRACKET MOTOR COVER 317-160-048 2
32 HOOK 5/8’’ SCOTCHMATE BACKING 317-160-056 2
33 HHWHTS #10-32 X .38 001-1755 4
34
HSHSS
∅
5/8’’ X 1’’ LONG
001-1730 2
35 NLN ½-13 001-1676 2
36
FW
∅
1/2’’
001-1443 2
37 ELEVATION DELRIN SPACER 317-160-060 4
38 NLN 3/8-16 001-1430 1
39 WASHER NYLON 317-160-086 4
40 HHCS 3/8-16 X 3’’ GR5 001-1699 1
41 ELEVATION ASSEMBLY 317-372-001 1
42 BUMPER 1.8 Dia. Black 317-160-106 2
B-8 TMX425 Series Owner’s Manual February 1, 2004
