TRACKMASTER
Running Deck Assembly
Item Description Part Number
Qty
1 ROLLER FRONT 317-160-003 1
2 HSHCS 5/16-18 X 2” PLTD 001-1748 1
3 LW 5/16” DIA. 001-1451 1
4 FW 5/16” DIA. 001-1440 1
5 SPACER FRONT END CAP 317-160-049 2
6 HSBHCS 5/16-18 X 2.75” PLT 001-1741 2
7 FRAME ASSEMBLY 220V FULLY ASSEMBLED 317-200-1-2 1
8 DECK RUNNING BOARD 317-160-025 1
9 1.75 DECK ISOLATOR WITH STUD 317-345-003 6
10 FW 5/16” DIA. 001-1440 6
11 LW 5/16” DIA. 001-1451 6
12 HHCS 5/16-18 X .75” 001-1167 6
13 HNS 5/16 – 18 FLANGE 001-1398 6
14 HSFCHCS 5/16-18 X 1.5 PLTD 001-1739 6
15 RUNNING BELT WITH GUIDE 317-160-002 1
16 HSHCS 5/16-18 X 3” PLTS 001-1740 2
17 SPACER REAR END CAP 317-160-050 2
18 HSBHCS 5/16-18 X 2” PLTD 001-1740 2
19 CAP END CHANNEL 317-160-022 4
20 FW 5/16” DIA. 001-1440 2
21 PLATE BELT TENSION 317-160-044 2
22 CHANNEL WELDMENT DECK SPT 317-379-001 3
23 ROLLER REAR 317-160-004 1
B-10 TMX425 Series Owner’s Manual February 1, 2004
