TRACKMASTER
Final Assembly
Item Description Part Number Qty
1 ESB ASSEMBLY 317-180-001 1
2 TUBE CONECTOR 317-160-021 4
3 TUBE SPACER 317-160-047 2
4 CENTER HANDRAIL 317-172-001 1
5 LW 5/16’’ DIA. HI-COLLAR 001-1738 2
6 HSHCS 5/16-18 X 3’’ 001-1737 2
7 PLUG DOME 317-160-039 2
8 LEFT HAND HANDRAIL WELDMENT 317-174-001 1
9 CLAMP SUPPORT 317-160-092 1
10 LW 5/16’’ DIA. INTERNAL TOOTH 001-1736 4
11 HSBHCS 5/16-18 X 1’’ 001-1735 4
12 HOOD ASSEMBLY 317-185-001 1
13 HWHTCS #8-32 X .75’’, TYPE F 001-1759 3
14 RUNNING DECK ASS’Y 220v FULLY
ASSEMBLED
317-200-1-3 1
15 DECAL SERIAL NUMBER 317-160-085 1
16 HNS 5/16-18 FLANGE 001-1398 4
17 U-BOLT 317-160-064 2
18 GROMMET HOOD 317-160-017 2
19 WARNING CARD ASSEMBLY 317-190-001 1
20 RIGHT HAND HANDRAIL WELDMENT 317-173-001 1
21 FASTNER 1/420 RIV-NUT 001-1686 1
22 CONNECTOR TUBE MODIFIED 317-184-002 1
23 FW 1/4’’ 001-1439 1
24 LW ¼’’ 001-1450 1
25 HHCS ¼-20 X 2’’ GR5 001-1493 1
B-12 TMX425 Series Owner’s Manual February 1, 2004
