Tractel Tralift User Manual

5
GB
W.L.L.* (t) 0.5 1 1.5 2 3 5 10 20
Standard lifting height (m)
(1)
3
Minimum distance between hooks
H (mm)
270 317 399 414 440 465 618 798 890
Tensile stress on hand chain at
W.L.L. (N)
200 320 360 365 328 385 435 435
435
× 2
Number of hand chains 1 2
Number of strands (load chain) 1 2 4 8
Measurements ∅ × D (see g. 5.1) of
load chain
6 × 18 8 × 24 6 × 18 8 × 24 10 × 30
Measurements ∅ × D (see g. 5.1) of
hand chain (mm)
5 × 25
Measurements (mm)
A 137 162 183 194 189 220 288 384 625
B 137.5 146.5 170 170 146.5 170 190 190 209
C 81 84 90 90 84 90 100 100 107
D 21 25 27 33 33 37 42 54 81
∅
34 40 44 51 51 54 66 84 110
M 42 47 50 64 64 67 78 92
Net weight (kg) 9.5 11.7 16.9 18.8 14.8 21.4 42 81.9 173.5
Additional weight per m. lifted (kg) 1.7 1.7 2.3 2.3 3.4 3.7 5.3 9.7 19.4
Maximum lifting height (m)
(2)
30 55 70 85 55 80 90 40 20
Maximum lifting height (m) with chain
cover option
(3)
35 35 30 30 20 20 12
(1)
: other lifting heights available as standard supply for: 0.5 t. to 20 t. models: 4 m, 5 m, 6 m.
(2)
: for greater lifting heights, contact TRACTEL
®
.
(3)
: contact TRACTEL
®
.
Options :
– all 0.5 t. to 20 t. models can be equipped optionally with a dynamic load limiter factory-set between 1.1 and
1.9 × WLL*
– chain bag: load chain storage bag (see table above).
