4
Attach Thermostat to Sub-Base
5
1. Line up the thermostat body with the sub-base.
2. Carefully push the thermostat body against the sub-base until it snaps
into place.
3. Insert quick reference card into slot on top of thermostat.
3
Setting User Options
Advanced User Options
User options allow you to customize some of your thermostat’s features.
Most users will not need to make any changes to the settings in this section.
To enter the User Options menu, hold down the RETURN button
for
approximately 3 seconds until the screen changes and displays the
first User Option.
Press the or button to change the setting for the displayed User Option.
After you have made your desired setting, press RETURN to advance to the
next User Option.
The thermostat will return to normal mode after your last user option is
made or after no keys have been pressed for 15 seconds.
User Factory Setting
No. Options Default Options Comments
1 1st stage
0.5
0.5, 1.0
Select a 1st stage temperature
differential
or 2.0 differential of .5˚, 1˚ or 2˚F (.2˚, .5˚
or 1˚C)
2
2nd stage
2.0
1.0, 2.0,
Select a 2nd stage temperature
differential
3.0, 4.0
, differential of 1˚, 2˚, 3˚, 4˚, 5˚ or 6˚F
(TP-P-521)
5.0
or
6.0
(.5˚, 1˚, 1.5˚, 2˚, 2.5˚ or 3˚C)
3
LNG
Selects long (permanent) hold mode
24HRS
Selects 24 hr. (temporary) hold mode
4
OFF
Disables filter service monitor feature
30, 60, 90
, Selects a number of days before
120, 180, the thermostat will flash a Service
365 Filter reminder in the display.
5 OF REC Disables adaptive (early)
recovery mode
ON REC Enables adaptive (early)
recovery mode
Table of User Options
Extended
Hold Period
LNG
Filter
Service
Monitor
OFF
Adaptive
Recovery
Mode (ARM
TM
)
OF REC
To Next Page
