37
Four (4) 8mm bolts and washers will
be used for the top weldment.
38
Two (2) long bolts, nuts and four (4)
washers along with two (2) long bolts
with washers only will be used to install the
side bars.
39
Side bar installation. Fit the left side
and right side bars into place.
40
Install the bolt with washer in the top
of the bar first.
41
Make sure the threads start into the
bar.
NOTE: DO NOT TIGHTEN HARDWARE YET.
42
Install the bolt, 2 washers and nut at
the bottom of the bar.
Repeat Steps 38-42 for other side bar.
NOTE: DO NOT TIGHTEN HARDWARE YET.
