49
Tighten ALL of the hardware previ-
ously installed into the cage at this
time with a 10mm wrench and a 12mm
wrench.
50
It is time to install the lower shock
bolts at the rear of the go-kart. Re-
move the bolt and nut from the frame at the
shock mount.
51
Have an assistant lift up on the rear
rack to align the shock with the
mount.
52
Align the shock.
53
Insert the bolt and nut.
54
Tighten the bolt and nut with two (2)
14mm wrenches.
NOTE: Repeat Steps 50-54 for the other side.
