Overall Length 87 in.(2210mm)
Overall Width 53.5 in.(1346mm)
Overall Height 56.6 in.(1438mm)
Wheelbase 66.1 in.(1680mm)
Front Track 45.7in.(1160mm)
Rear Track 42.7 in.(1085mm)
Ground Clearance 8.5 in.(215mm)
DIMENSIONS
ENGINE
CAPACITIES
Type Water-cooled.4-Stroke
Engine capacity 300cc
Bore / Stroke 72.5mm x 66.8mm
Displacement 275.6cm
Corrected compression ratio 10:1
Carburetor VEKS4 & CV30
Output Power 13KW/ 6500RPM
Maximum Torque 22N.m/5000RPM
Starting Electri
Ignition C.D.I
Lubrication Force&Splash
Transmission Automatic(C.V.T system)
Spark Plug DR8EA(NGK)
Plug gap 0.6-0.7mm
Fuel Type Rq90(unleaded)
Lubricate oil SAE 15W -40/SF
Maximum load Do Uble Seats/400lbs
Fuel tank 25 Gal
Engine oil 30 Oz
Starting 5s
oo
Climbing 20 -25
Battery 12V 10Ah
Head Light 12V 35W /35W
Tail Light 12V 21W /5W
Fuse 10A
11
SPECIFICATIONS
DRIVE COMPONENTS
Gear box oil MoS2 & W -2DW-4D
