REPAIR
B. Rear Wheel Replacement
Do not disassemble the castle nuts when you replace the rear wheels and hub assembly.
Remove the cotter pin and then 24 mm nut.Then slide off the wheel and hub assembly.It is
only necessary to remove the 4 lug nuts to remove the wheel.Tighten the unts after repla-
cing the wheels.
21
Figure 12
C. Front Wheel Alignment
a.The front wheels should be toe-infrom 1/8 to 1/4 inch.To check for alignment,measure
distance A and B between the centerline(CL)of the wheels. The proper toe-in dimension A
should be 1/8 to 1/4 inch greater than dimension B.
b.To adjust the alignments,loosen the lock nuts on both sides of Front Tie Rods.To make
Dimension B smaller,tum the rod to left. Adjust the rod to right direction to make
Dimension B larger. After adjusting to the desired length,tighten the lock nut against the rod
end. Recheck the dimensions for proper alignment.
