Front Wheel Replacement
Do not disassemble the castle nuts when you
replace the front wheels.
It is only necessary to remove the four lug nuts to
remove the wheel. Tighten the nuts after replacing
the wheels.
Rear Wheel Replacement
Do not disassemble the castle nuts when you
replace the rear wheels and hub assembly.
Remove the cotter pin and then 24mm nut. Then
slide off wheel and hub assembly. It is only
necessarytoremovethefourlugnutstoremovethe
wheels byitself.
Front Wheel Alignment
Thefrontwheelsshouldbesetwitha“toe‐in”from
1/4” to 3/8”. At the center‐line of the tires,
measure the Distance A and the Distance B. For
propertoeadjustment,DimensionAshouldbe1/4”
– 3/8” greater than Dimension B.
1)
LoosenthelocknutsonbothsidesofFrontTie
Rods.
Ensure the steering wheel is centered, and
adjustDimensionBbyequallyrotatingthetie
rods in or out with a12mmwrench.
2)
Afteradjustingtothedesiredlength,tightenthe
lock nuts against the rodend.
3)
Recheckthedimensionsforproperalignment.
