64
Install the cotter pin into the axle nut.
Bend one end of the cotter pin over
the end of the axle. Clip off other end with
cutters.
GOKARTMASTERS.COM
62
Place the largest washer and castle
nut onto the axle.
63
Tighten the castle nut securely and
align the holes in the axle with the
nut.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
61
Place the wheel onto the rear axle.
GOKARTMASTERS.COM
65
Install rubber hubcap over axle nut.
NOTE: Repeat Steps 60-65 for the driver’s
side rear wheel.
GOKARTMASTERS.COM
66
Lift front of go-kart and support with
jack stands.
