TrailMaster MINI XRX - Fuel Tank and Fuel System Setup; Mounting the Fuel Tank

37
Locate the fuel tank.
NOTE: On some models, the fuel tank
is already installed on the engine. Check tank
mounting hardware to insure tight. Proceed
to Step 46.
38
Locate 4 long bolts and nuts and fuel
hose clamp.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
40
Install the 4 bolts and nuts into the
tank.
41
Tighten with a 10mm & 12mm
wrenches.
GOKARTMASTERS.COM GOKARTMASTERS.COM
39
Place the fuel tank onto the rear rack
with decal to the rear.
GOKARTMASTERS.COM
42
Locate the end of the fuel hose on top
of the engine.
