TrailMax TD-40-T - 3.4 Running Gear

page 46
TD-40-T
®
3.4 Running Gear
For:
Brakes
Bearings and Hubs
Axle End Components
Refer to the Meritor Maintenance Manual 14, Trailer Axles and call Gem State Manufac-
turing at 1-800-447-0213.
Suspension
Ref. Quantity Description ................................................................................... Part No.
1. 1 Axle Assembly, Front (ABS) ............................................... TN4271QH6815
2. 1 Axle Assembly, Rear (non ABS) ......................................... TN4270QH6814
3. 2 Non-Adjustable Radius Rod .............................................................. 715-00
4. 4 Spring Seat ......................................................................................... 301-1
5. 2 Radius Rod, 19.25" ....................................................................... 16398-04
6. 8 Flanged Locknut ........................................................................... 10562-00
7. 8 Radius Rod Bolt ................................................................................ 719-02
8. 4 2 Leaf Medium Arch Spring ......................................................... TS-325-01
9. 8 U-bolt .............................................................................................. 7816-11
10. 4 Bottom Plate ..................................................................................... 706-01
11. 16 Washer ............................................................................................... 35-00
12. 16 Hex Nut ............................................................................................... 34-04
1 Equalizer Bolt Kit ....................................................................... 10287-00
13. 4 Spacer sleeve ............................................................................. 756-00
14. 4 Spacer sleeve bolt ...................................................................... 759-00
15. 4 Hex lock nut .................................................................................. 37-03
16. 4 Spring Brake Chamber, Type 2424 ......................................... B213276X24
Note: Kit names are bold type while component names are regular type; kit components
are indexed under the kit name. Kit component quantities are per kit; other parts and kit quan-
tities are per trailer.
*Rear Hanger includes spacer sleeve, bolt, and nut.
