TrailMax TD-40-T - Air Brake System

page 58
TD-40-T
®
3.6 Air Brake System
Because of the complexity of the air brake system, the components are displayed
graphically over the next several pages.
Ref. Quantity Description......................................................................... Part No.
1 Tandem Axle Air Kit/ABS ........................................ AK-A2 ABS-PC
1. 1 Service Gladhand ......................................................... PL12-006
2. 1 Emergency Gladhand ................................................... PL12-008
3. 2 Hose Assembly,
1
/2" x
1
/2" x 60" ............................. TA32003-060
4. 2 Male Elbow,
3
/8" x
3
/8" .................................... PBVS269NTA-6-6
5. 2 Male Elbow,
1
/2" x
3
/8" .................................... PBVS269NTA-8-6
6. 3 Terminal Bolt ................................................................... MI11304
7. 2 90° Union Elbow ..................................................... PB2200P-8-8
8. 360"
1
/2" Nylon Tubing, Red ...................................... NT PF8REDIN0E
9. 360"
3
/8" Nylon Tubing, Black ......................................... NT PF6BIN0E
10. 1 Air Tank, 1200/2800 cu. in. ............................................... AT1211
11. 4 Hose Assembly,
3
/8" x
3
/8" x 30" ............................. TA32002-030
12. 4 Hose Assembly,
3
/8" x
3
/8" x 62" ............................. TA32002-062
13. 3 Street Elbow, 90° .................................................... PB2200P-6-6
14. 1 Drain Cock ............................................................... PBDC604-4
15. 1 Allen Head Pipe Plug ......................................................... F1 3/4
16. 1 Hose Assembly,
3
/8" x
3
/8" x 28" ............................. TA32002-028
17. 1 Electronic Control Unit (ECU) ............................. OW4005001020
18. 1 Pipe Nipple................................................................. F1 60060E
19. 1 Male Branch Tee
3
/8" x
1
/4" .............................PBVS272NTA-6-4
20. 1 Street Elbow, 45° .................................................... PB2214P-6-6
21. 1 Spring Brake Control Valve ..................................... OS1105000E
22. 4 Allen Head Pipe Plug .....................................................F1 3/8AP
Note: Kit names are bold type while component names are regular type; kit com-
ponents are indexed under the kit name. Kit component quantities are per kit; other
parts and kit quantities are per trailer.
