CONCRETE MOISTURE ENCOUNTER X5 USER GUIDE
11
OPERATING INSTRUCTIONS
1. Ambient RH Probe
2. Digital display
3. Menu button
4. Hold button
5. Bluetooth ON/OFF
6. Bayonet connection for Wood Probe
7. Light button
8. SCROLL UP button
9. SELECT button
10. ON/OFF button
11. SCROLL DOWN button
The instrument face with brief notes on the push button
controls and LCD is shown below.
85mm
1
6
4
7
3
160 mm
2
9
5
8
10
11
