8
18-BB42D1-1B-EN
Figure 2. Bottom and Back Duct Openings
B
C
D
E
F
E
G
H
M
L
J
J
I
K
N
Height
mm (in)
A B C D E F G H I J K L M N
4WCZ5024
4WCZ5036
4WCZ5048
4WCZ5060
PHYSICAL DIMENSIONS mm (in)
86.25
(3.39)
449.02
(17.67)
176.07
(6.93)
329.58
(12.97)
372.82
(14.67)
1351.95
(53.22)
176.68
(6.95)
296.62
(11.67)
1155.45
(45.49)
457.20
(18.0)
82.16
(3.23)
82.16
(3.23)
381.00
(15.0)
244.09
(9.61)
325.49
(12.80)
381.00
(15.0)
167.89
(6.61)
173.46
(6.83)
304.80
(12.0)
48.35
(1.90)
398.22
(15.67)
176.07
(6.93)
949.33
(37.37)
1050.93
(41.37)
304.80
(12.0)
92.33
(3.63)
66.51
(2.62)
406.40
(16.0)
W1 W2 W3 W4 BB CC
4WCZ5024 60.8 [134] 38.1 [84] 27.2 [60] 42.6 [94] 200.5 [442] 168.7 [372] 401.3 [15.8] 508 [20]
4WCZ5036 60.8 [134] 38.1 [84] 27.2 [60] 42.6 [94] 200.5 [442] 168.7 [372] 401.3 [15.8] 508 [20]
4WCZ5048 68.9 [152] 40.8 [90] 30.8 [68] 52.2 [115] 275.6 [607] 217.5 [479] 414.0 [16.3] 635 [25]
4WCZ5060 80.3 [177] 47.6 [105] 35.8 [79] 60.8 [134] 282.8 [623] 224.5 [495] 414.0 [16.3] 635 [25]
Corner Weights KG/LBS
SHIPPING WEIGHT
KG/LBS
UNIT WEIGHT
KG/LBS
Center Of Gravity mm[inch]
457.20
(18.0)
DDeetteerrmmiinnee UUnniitt CClleeaarraanncceess
