38
18-EB40D1-1A-EN
4YCC4048E1070
EXTERNAL STATIC PRESSURE (IN.WG)
Horizontal Airflow [Down Airflow]
Motor Speed
0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Constant
Circulation
CFM
APPROXIMATELY 40-50% COOLING OR HEATING AIRFLOW
WATTS
Cooling - Low
CFM
1583
(1567)
1542
(1526)
1502
(1487)
1460
(1445)
1415
(1401)
- - - - - -
WATTS
302
(308)
313
(320)
324
(330)
332
(339)
346
(352)
- - - - - -
Cooling - Med
CFM
1763
(1745)
1723
(1706)
1689
(1672)
1648
(1632)
1609
(1593)
1568
(1552)
1527
(1512)
1488
(1473)
1447
(1433)
- -
WATTS
414
(422)
426
(434)
436
(444)
448
(457)
459
(468)
471
(480)
483
(493)
495
(505)
510
(520)
- -
Cooling - Med High
CFM -
1786
(1768)
1757
(1739)
1729
(1712)
1700
(1683)
1675
(1658)
1648
(1632)
1624
(1608)
1504
(1489)
- -
WATTS -
577
(589)
591
(603)
604
(616)
617
(629)
631
(644)
643
(656)
655
(668)
599
(611)
- -
Cooling - High
CFM - - - - -
1769
(1751)
1728
(1711)
1688
(1671)
1652
(1635)
1545
(1530)
-
WATTS - - - - -
613
(625)
631
(644)
643
(656)
647
(660)
611
(623)
-
Heating - Low
CFM
1120
(1126)
1047
(1052)
980
(985)
914
(918)
840
(845)
758
(762)
674
(677)
581
(584)
- - -
WATTS
117
(117)
126
(127)
135
(136)
145
(146)
156
(156)
168
(168)
179
(180)
188
(189)
- - -
Heating - High
CFM -
1204
(1210)
1149
(1154)
1095
(1100)
1043
(1048)
989
(994)
926
(930)
858
(862)
798
(802)
- -
WATTS -
176
(177)
185
(186)
195
(196)
205
(206)
216
(217)
227
(228)
239
(240)
249
(250)
- -
Note: Cooling airflow must not exceed 1800 CFM due to condensate blowoff.
4YCC4048E1090
EXTERNAL STATIC PRESSURE (IN.WG)
Horizontal Airflow [Down Airflow]
Motor Speed
0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Constant
Circulation
CFM
APPROXIMATELY 40-50% COOLING OR HEATING AIRFLOW
WATTS
Cooling - Low
CFM
1583
(1567)
1542
(1526)
1502
(1487)
1460
(1445)
1415
(1401)
- - - - - -
WATTS
302
(308)
313
(320)
324
(330)
332
(339)
346
(352)
- - - - - -
Cooling - Med
CFM
1763
(1745)
1723
(1706)
1689
(1672)
1648
(1632)
1609
(1593)
1568
(1552)
1527
(1512)
1488
(1473)
1447
(1433)
- -
WATTS
414
(422)
426
(434)
436
(444)
448
(457)
459
(468)
471
(480)
483
(493)
495
(505)
510
(520)
- -
Cooling - Med High
CFM -
1786
(1768)
1757
(1739)
1729
(1712)
1700
(1683)
1675
(1658)
1648
(1632)
1624
(1608)
1504
(1489)
- -
WATTS -
577
(589)
591
(603)
604
(616)
617
(629)
631
(644)
643
(656)
655
(668)
599
(611)
- -
Cooling - High
CFM - - - - -
1769
(1751)
1728
(1711)
1688
(1671)
1652
(1635)
1545
(1530)
-
WATTS - - - - -
613
(625)
631
(644)
643
(656)
647
(660)
611
(623)
-
Heating - Low
CFM
1419
(1426)
1380
(1387)
1341
(1348)
1295
(1301)
1249
(1255)
1204
(1210)
1160
(1166)
1115
(1120)
1069
(1074)
1015
(1020)
961
(966)
WATTS
240
(241)
250
(251)
259
(260)
269
(270)
279
(281)
291
(292)
302
(303)
312
(314)
323
(325)
333
(335)
348
(349)
Heating - High
CFM
1559
(1567)
1524
(1531)
1483
(1491)
1443
(1450)
1401
(1408)
1363
(1370)
1319
(1326)
1276
(1282)
1233
(1239)
1195
(1201)
1147
(1152)
WATTS
313
(315)
324
(325)
335
(337)
346
(347)
356
(358)
367
(368)
379
(381)
392
(394)
403
(405)
415
(417)
428
(430)
Note: Cooling airflow must not exceed 1800 CFM due to condensate blowoff.
