Table 1. Unit weights (continued)
Without Starters With Starters
Operating Weights Shipping Weights Operating Weights Shipping Weights
MODEL NTON CPKW EVSZ CDSZ lb kg lb kg lb kg lb kg
C
V
H
G
480–565 489 050L 050L 23384 10607 20815 9442 24466 11098 21897 9932
480–565 489 060S 060L 22046 10000 19866 9011 3128 10491 20948 9502
480–565 489 050S 050S 21323 9672 19324 8765 22405 1063 20406 9256
480–565 489 080L 080L 31955 14495 28003 12702 33037 14986 29085 13193
480–565 489 080S 080L 29792 13514 26391 11971 30874 14004 27473 12462
480–656 489 080S 080S 29154 13224 26065 11823 30236 13715 27147 12314
670–780 621 080L 080L 33266 15089 29314 13297 34348 15580 30396 13788
670–780 621 080S 080L 31103 14108 27702 12566 32185 14599 28784 13056
670–780 621 080S 080S 30465 13819 27376 12418 31547 14310 28458 12909
670–780 621 142L 142L 44705 20278 38442 17437 45787 20769 39524 17928
670–780 621 142M 142L 43514 19738 37619 17064 44596 20229 38701 17555
920–1067 621 142L 142L 45545 20659 39282 17818 46627 21150 40364 18309
920–1067 621 142M 142L 44354 20119 38459 17445 46436 20610 39541 17936
920–1067 621 210L 210L 57319 26000 49375 22397 58401 26491 50457 22887
1100 621 142L 142L 45625 20695 39362 17854 46707 21186 40444 18346
1100 621 142M 142L 44434 20155 38539 17481 45516 20646 39621 17972
1100 621 210L 210L 57399 26036 49455 22432 58481 26527 50537 22923
C
V
H
E
190–270 242 032L 032L 16719 7584 15173 6882 17801 8075 16255 7373
190–270 242 032S 032L 15823 7177 14512 6583 16905 7668 15594 7073
190–270 242 032S 032S 14988 6799 13758 6241 16070 7289 14840 6731
190–270 242 050L 050L 20678 9380 18109 8214 21760 9870 19191 8705
190–270 242 050S 050L 19340 8773 17160 7784 20422 9263 18242 8275
190–270 242 050S 050S 18306 8304 16276 7383 19388 8794 17358 7874
300–420 379 050L 050L 21569 9784 19000 8618 22651 10274 20082 9109
300–420 379 050S 050L 20231 9177 18051 8188 21313 9668 19133 8679
300–420 379 050S 050S 19197 8708 17167 7787 20279 9199 18249 8278
300–420 379 080L 080L 30140 13672 26188 11879 31222 14162 27270 12370
300–420 379 080S 080L 27977 12690 24576 11148 29059 13181 25658 11638
300–420 379 080S 080S 26567 12037 23398 10613 27619 12528 24480 11104
EVSZ 050 080
142M&L 210
050
DSTF
080
DSTF
150psi 300psi 150psi 300psi
B 1473 1822 2194 2222 2454 2486 1646 2080
SHELL
LENGTH TYPE
S L M E
A 3489 4638 4124 5210
EVSZ 142E 250E
150psi 300psi
B 2194 2222 2797
C 1270 1301 1705
D 293 293 343
E 406 406 483
F 572 572 572
G 4506 4506 4506
30
51
51
B
51
B
A
GF
EVAPORATOR
TUBESHEET
EVAPORATOR
TUBESHEET
Ø22.3
A
EVAPORATOR
TUBESHEET
EVAPORATOR
TUBESHEET
Ø22.3
51
C
D
E
30 30
14 TCVHE-SVX04D-EN
Unit Dimensions and Weights
