Trane Technologies CVHF - Sound Pressure Level; 60 Hz with AHRI relief (dBA); 60 Hz with AHRI relief (dBA) (continued); 50 Hz with AHRI relief and starter (dBA)

60 Hz with AHRI relief (dBA)
Model
Condenser
Shell Size
Freq.
Drive
Typical Sound Pressure
100%
Load
75%
Load
50%
Load
25%
Load
CVHS 300
030A, 030A Y 70 68 68 67
030B, 030B Y 70 68 68 67
CVHE 230–250
032S, 032L
Y 77 77 77 77
N 77 78 78 78
050S, 050L
Y 78 77 77 77
N 78 78 78 78
CVHE 280
032S, 032L
Y 78777776
N77767677
050S, 050L
Y 78777776
N77767677
CVHE 320
032S, 032L
Y 77 76 76 75
N 77 78 78 78
050S, 050L
Y 78 78 78 78
N 78 78 80 80
CVHE 360–400
050S, 050L
Y 78787777
N78798080
080S, 080L
Y 78787878
N78798080
CVHE 450
050S, 050L
Y 78 77 76 76
N 77 77 78 79
080S, 080L
Y 78 77 76 76
N 77 77 78 79
CVHE 500
050S, 050L
Y 79777676
N78787979
080S, 080L
Y 79777676
N78787979
CVHF 350
050S, 050L
Y 79 78 78 79
N 79 78 80 81
080S, 080L
Y 79 78 78 79
N 79 78 80 81
CVHF 410
050S, 050L
Y 78777677
N79787981
080S, 080L
Y 78777677
N80798081
CVHF 485
050S, 050L
Y 80 78 77 78
N 79 78 79 82
080S, 080L
Y 80 78 77 78
N 79 79 79 82
CVHF 570
050S, 050L
Y 80787777
N80798083
080S, 080L
Y 80787777
N80797883
CVHF 620–650
080S, 080L
Y 81 79 78 78
N 80 79 81 83
142L
Y 81 79 79 79
N 80 80 81 83
CVHF 760–770
080S, 080L
Y 81787677
N81798083
142L
Y 82797677
N82818183
CVHF 870–910
080S, 080L
Y 82 79 77 78
N 82 82 81 83
142L
Y 82 78 76 77
N 83 82 83 84
CVHF 1070
142L
Y 82797777
N82818385
210L, 250L
Y 82797778
N82828385
CVHF 1300
142L
Y 82 79 77 77
N 83 83 84 85
210, 250L
Y 83 81 78 79
N 83 83 84 85
CVHF 1470
210L
Y 83807978
N83828283
250L
Y 84828079
N83838283
CVHF 1720
210L
Y 84 81 79 80
N 84 82 82 83
250L
Y 84 81 79 80
N 84 82 82 83
CDHF 1500 210D
Y 85838281
N85838384
CDHF 2000 210D
Y 84 82 80 79
N 84 82 82 83
CDHF 2170 250D
Y 85828180
N85828182
CDHF 2550 250D
Y 87 84 83 82
N 87 84 83 84
CDHF 3000 250M
Y 91919191
N91919191
50 Hz with AHRI relief and starter (dBA)
Model
Condenser
Shell Size
Typical Sound Pressure
100%
Load
75%
Load
50%
Load
25%
Load
CVHE 190–270
032S, 032L 78 78 79 81
050S, 050L 78 78 79 81
CVHE 300–330
050S, 050L 77 77 78 80
080S, 080L 77 77 78 80
CVHE 370–420
050S, 050L 78 78 79 81
080S, 080L 78 78 79 81
CVHG 480
050S, 050L 79 78 79 81
080S, 080L 79 78 79 81
CVHG 565
050S, 050L 79 79 80 82
080S, 080L 79 79 80 82
CVHG 670
080S, 080L 80 78 79 81
142L 80 78 79 81
CVHG 780
080S, 080L 80 80 81 82
142L 81 80 81 83
CVHG 920
142L 81 81 82 83
210L 81 81 82 83
CVHG 1100
142L 81 81 83 84
210L 81 81 83 84
60 Hz with AHRI
relief (dBA) (continued)
Model
Condenser
Shell Size
Freq.
Drive
Typical Sound Pressure
100%
Load
75%
Load
50%
Load
25%
Load
TCVHE-SVX04D-EN 74
