Trane 13.4 SEER2 J4PH4 Series - Page 5

Decorative
protective
coil guard
Highly efficient enhanced
aluminum / aluminum fin
indoor coil
Highly efficient enhanced
copper tube/Aluminum fin
outdoor coil
Condenser fan
motor
Blower motor with
slide-out blower
assembly
Electric heater
assembly (optional)
Compressor
Heavy gauge removable
base rails
Fig. 2-1 Component Location
* The above figure for reference purpose only.
