Fig. 2-2 Unit Dimensions
Unit size: 024, 030, 036
* The above figure for reference purpose only.
Hi./Lo.
pressure
service port
1/4’’ SAE
Condensate drain
connection 3/4” NPTI
(Trap required)
Low voltage entrance 7/8” Dia.
High voltage conn. 1-3/8” Dia.
Front
Electrical service access
compartment panel
37-3/4″
21-9/16″
52″
5-7/8″
6-5/8″
24-13/16″
12-11/16″
6-5/8″
18-1/2″
6-5/8″
8-9/16″
6-5/8″
3-11/16″
3″
3″
4-5/16″
1-9/16″
2-3/8″
04
