Trane 2MCC05-C User Manual

MS-SVN056C-EN 29
Convertible Unit Installation
Ceiling installation
Wall installation
20mm
D. Refrigerant line
connection
(D. gas side)
Draining point
Downward pitch between (1-2)/100
E. Refrigerant line
connection
(E. liquid side)
Unit dimensions
unit˖mm
MODEL
24
18
AB DEC
1068 675 235 983
220675 235 1565
1650
220
1285 675 235 1200
220
36-60
