28 MS-SVN056C-EN
Convertible Unit Installation
Steel beam ceilings
Install using a steel support rafter/beam.
Unit installation
• Remove side panels and grille
• Place hanging anchors over the hanging rods.
Anchor bolt
Steel support rafter
Hanging rods
Side panel
Grille
Hanging anchors
Carriage
bolt
Nut
Washer
Hanging rod
Hanging anchor
2025mm
