Installer’s Guide
Figure 13. Typical Rooftop Down Airflow Application with Frame
Figure 12. Typical Rooftop Horizontal Airflow Application with Frame
Supply Air
Return Air
Roof Flashing
Channel Iron Center
Support (Center Sup-
port required on all
Frame Applications.)
Angle Iron Frame
Roof Flashing
Return Air
Angle Iron Frame
Roof Flashing
Supply Air
Channel Iron Center Support
(Center Support required on all
Frame Applications.)

Trane 4DCY4024 Specifications

General

Brand	Trane
Model	4DCY4024
Category	Air Conditioner
Language	English
