Table 19. Auxiliary Heating Airflow, Horizontal or Downflow from 0.2 to 0.6" wg
Switch Settings
Selection
Nominal Airflow
4DCZ5024 4DCZ5036 4DCZ5048 4DCZ5060
Low Stage
High
Stage
Low Stage
High
Stage
Low Stage
High
Stage
Low Stage
High
Stage
7-OFF 8-OFF A 600 850 725 1000 1075 1375 1375 1800
7-ON 8-OFF B 625 900 775 1075 1100 1450 1450 1900
7-OFF 8-ON C 650 925 850 1150 1150 1500 - -
7-ON 8-ON D 700 975 925 1250 1200 1575 - -
UUnniitt SSttaarrttuupp
