Product Specifications
MODEL
4DCZ5024*1
(060)
4DCZ5036*1
(070)
4DCZ5048*1
(090)
4DCZ5060*1
(115)
RATED Volts/PH/Hz 208-230 / 1 / 60
Performance Cooling BTUH
(a)
BTUH (High)
23800 35200 47500 56500
Indoor Airflow (CFM)
800 1110 1625 1775
Power Input (KW) 1.98
3.03 4.12 5.12
Indoor Airflow (CFM) (Low)
630 830 1240 1250
Power Input (KW) 1.17
1.71 2.31 2.85
EER2 / SEER2 11 / 15.2 11 / 15 11 / 14.65
Sound Power Rating [dB(A)]
(b)
66.8 70 72 74
HP Heating Performance
(High Temp.) BTUH/COP (High)
23200 / 3.6 31000 / 3.47 43000 / 3.71 55500 / 3.58
Power Input (KW)
1.89 2.75 3.48 4.62
(Low Temp.) BTUH/COP (High)
13600 / 2.34 19400 / 2.16 25000 / 2.29 35000 / 2.44
Power Input (KW)
1.70 2.64 3.20 4.20
(High Temp.) BTUH/COP (Low)
16300 / 3.41 22400 / 3.26 32000 / 3.77 37600 / 3.38
Power Input (KW)
1.40 2.02 2.49 3.26
(Low Temp.) BTUH/COP (Low)
7900 / 1.77 11200 / 1.57 17300 / 2.08 19400 / 1.80
Power Input (KW) 1.31
2.09 2.44 3.15
HSPF2 (BTUH/Watt-Hr)
(c)
7.25 6.7 6.7 7.45
Gas Heating Performance
(d)
Input BTUH - 1st Stage (Nat. Gas)
48600 56000 72000 92000
Input BTUH - 2nd Stage (Nat. Gas)
60000 70000 90000 115000
AFUE 81
Temp. Rise-Min/Max (°F)
40 / 70 30 / 60
Orifice Qty / Drill Size (Nat. Gas)
(e)
2 / #37 2 / #33 3 / #37 3 / #32
POWER CONN. — V/Ph/Hz 208-230/1/60
Min. Brch. Cir. Ampacity
(f)
LOCATED ON UNIT NAMEPLATE
Fuse Size — Max. (amps) LOCATED ON UNIT NAMEPLATE
COMPRESSOR 2 STAGE SCROLL
VOLTS/PH/HZ 208-230/1/60
R.L. Amps — L.R. Amps LOCATED ON UNIT NAMEPLATE
OUTDOOR COIL — TYPE SPINE FIN
Rows/F.P.I 2 / 24
Face Area (sq. ft.)
15.49 23.57
Tube Size (in.) 3/8
