6
18-BG07D1-1B-EN
MODEL
4DCZ5024*1
(060)
4DCZ5036*1
(070)
4DCZ5048*1
(090)
4DCZ5060*1
(115)
INDOOR COIL — TYPE PLATE FIN
Rows/F.P.I 4/15
Face Area (sq. ft.)
3.5 5.0
Tube Size (in.) 3/8
Refrigeration Control
EXPANSION VALVE
Drain Conn. Size (in.) 3/4 FEMALE NPT
OUTDOOR FAN — TYPE PROPELLER
DIA. (IN.)
23.4 28.2
DRIVE/NO. SPEEDS 1 / 1
CFM @ 0.0 in. w.g.
(g)
2550 3000 4200 4700
Motor — HP/R.P.M 1/12 /810 1/6 /830 1/6 /830 1/4 /830
Volts/Ph/Hz 208–230/1/60
F.L. Amps/L.R Amps
LOCATED ON UNIT NAMEPLATE
INDOOR FAN — TYPE CENTRIFUGAL
Dia. x Width (in.)
10 x 10 11 x 10
Drive/No. Speeds DIRECT / VARIABLE
CFM @ 0.0 in. w.g.
(h)
SEE FAN PERFORMANCE TABLE
Motor — HP / R.P.M. 1/2 /VARIABLE 3/4 /VARIABLE 1/VARIABLE
Volts/Ph/Hz 208–230/1/60
F.L. Amps LOCATED ON UNIT NAMEPLATE
COMBUSTION FAN — TYPE CENTRIFUGAL
Drive/No. Speeds DIRECT / 2
Motor — HP / R.P.M. 1/20 / 3350 /2600
Volts/Ph/Hz 208–230/1/60
FILTER / FURNISHED NO
Type Recommended THROWAWAY
Recmd. Face Area (sq. ft) (g)
4.0 5.3
REFRIGERANT R-410A
Charge (lbs.)
LOCATED ON UNIT NAMEPLATE
Subcooling 8°
10°
(a)
Certified in accordance with the Unitary Air-Conditioner Equipment certification program, which is based on AHRI Standard 210/240. Noise calculated in
accordance with AHRI Standard 270.
(b)
Sound Power values are not adjusted for AHRI 270-95 tonal corrections.
(c)
Filters must be installed in return air stream. Square footages listed are based on 300 f.p.m. face velocity. If permanent filters are used size per
manufacturer's recommendation with a clean resistance of 0.05" W.C.
(d)
All models are certified to UL 1995. Ratings shown are for elevations up to 2000 ft. For higher elevations reduce ratings at a rate of 4% per 1000 ft.
elevation.
(e)
Convertible to LPG.
(f)
This value is approximate. For more precise value, see Unit Nameplate.
(g)
Standard Air - Dry Coil - Outdoor.
(h)
Based on U.S. Government Standard Tests.
IInnttrroodduuccttiioonn,, UUnniitt IInnssppeeccttiioonn aanndd SSppeecciiffiiccaattiioonn
