Trane 4DCZ5024F1060A - Page 9

18-BG07D1-1B-EN
9
Figure 2. Bottom and Back Duct Openings
I
J
J
L
M
G
B
E
D
F
E
C
K
H
N
949.33 [37 - 3/8]
1050.93 [41 - 3/8]
Height mm [in]
A -Height B C D E F G H I J K L M N
4DCZ5036E
4DCZ5048E
4DCZ5060E
1355.64
[53.37]
381.00
[15.0]
88.21
[3.47]
449.02
[17.68]
176.07
[6.93]
331.54
[13.05]
372.82
[14.68]
176.07
[6.93]
184.29
[7.26]
296.62
[11.68]
1108.75
[43.50]
457.20
[18.0]
85.60
[3.37]
381.00
[15.0]
244.09
[9.61]
327.45
[12.89]
PHYSICAL DIMENSIONS mm [in]
304.80
[12.0]
84.46
[3.32]
82.16
[3.23]
406.40
[16.0]
167.89
[6.61]
180.20
[7.1]
304.80
[12.0]
86.25
[3.40]
398.22
[15.68]
84.12
[3.31]
W1 W2 W3 W4 BB CC
4DCZ5036E
62.1 [137] 37.2 [82] 30.4 [67] 50.3 [111] 221.6 [488] 178 [392] 386 [15.2] 558.8 [22]
4DCZ5048E
81.6 [180] 46.3 [102] 42.2 [93] 73.5 [162] 301.6 [665] 243.6 [537] 419.1 [16.5] 706.1 [27.8]
4DCZ5060E
83.9 [185] 47.2 [104] 43.1 [95] 75.7 [169] 306.9 [676] 248.8 [548] 398.8 [15.71] 711.2 [28]
Corner Weights
KG/LBS
SHIPPING
WEIGHT
KG/LBS
UNIT
WEIGHT
KG/LBS
Center Of Gravity
mm[inch]
106.45
[4 - 3/16]
148.92
[5 - 7/8]
119.74
[4 - 23/32]
27.78
[1 - 3/32]
4DCZ5024F
62.1 [137] 37.2 [82] 30.4 [67] 50.3 [111] 221.6 [488] 178 [392] 386 [15.2] 558.8 [22]
4DCZ5024F
DDeetteerrmmiinnee UUnniitt CClleeaarraanncceess
