Trane 4WCY4036B3 - Determine Unit Clearances

18-BB34D1-19B-EN
7
Determine Unit Clearances
Figure 1. Space on Sides Requirements
CC
DD
BB
FF
EE
W/ ECONOMIZER W/ ECONOMIZER
BACK SIDE 305 [12] 762 [30] 305 [12] 762 [30]
LEFT SIDE 762 [30] 914 [36] 914 [36] 1067 [42]
RIGHT SIDE 610 [24] - 610 [24] -
FRONT SIDE 1067 [42] - 762 [30] -
BOTTOM
BACK SIDE
LEFT SIDE
RIGHT SIDE
FRONT SIDE
TOP
A
BB
CC
DD -Depth
EE -Width
FF 497.8 [19-5/8] 576.00 [22-11/16]
CENTER OF GRAVITY - TABLE NEXT PAGE
CENTER OF GRAVITY - TABLE NEXT PAGE
1093.72 [43-1/16] 1173.99 [46-1/4]
1284.99 [50-5/8] 1535.94 [60-1/2]
305 [12] 305 [12]
914 [36] 914 [36]
DIMENSIONS mm [Inches]
HEIGHT OF UNIT - TABLE NEXT PAGE
25 [1] 25 [1]
152 [6] 152 [6]
152 [6] 152 [6]
2 - 3 TON Units 3.5 - 5 TON Units
RECOMMENDED SERVICE CLEARANCE mm [Inches]
CLEARANCE TO COMBUSTIBLE MATERIAL mm [Inches]
0 0
