Trane 4YCZ5024F1060A User Manual

18-EB41D1-1B-EN
9
Figure 2. Bottom and Back Duct Openings
B
C
D
E
E
F
G
H
BOTTOM DUCT OPENINGS
I
J
J
K
L
M
N
BACK DUCT OPENINGS
BACK SIDE
RIGHT SIDE
903.29 [35 - 3/8]
1050.93 [41 - 3/8]
Height mm [in]
A -Height B C D E F G H I J K L M N
4YCZ5024
4YCZ5048 (115)
4YCZ5060
1355.64
[53.37]
381.00
[15.0]
88.21
[3.47]
449.02
[17.68]
176.07
[6.93]
331.54
[13.05]
372.82
[14.68]
176.07
[6.93]
184.29
[7.26]
296.62
[11.68]
1108.75
[43.50]
457.20
[18.0]
85.60
[3.37]
381.00
[15.0]
244.09
[9.61]
327.45
[12.89]
PHYSICAL DIMENSIONS mm [in]
304.80
[12.0]
75.41
[2.93]
406.40
[16.0]
167.89
[6.61]
180.20
[7.1]
380.21
[14.96]
79.50
[3.13]
398.22
[15.68]
84.12
[3.31]
W1 W2 W3 W4 BB CC
4YCZ5024 60.3 [133] 38.1 [84] 26.8 [59] 42.6 [94] 199.6 [440] 167.8 [370] 406.0 [16.0] 533.4 [21.0]
61.0 [134] 38.0 [84] 31.0 [69] 49.0 [107] 218.0 [481] 175.0 [385] 399.0 [15.7] 546.0 [21.5]
4YCZ5036 (090) 61.0 [134] 37.0 [81] 31.0 [69] 51.0 [113] 226.0 [498] 182.0 [402] 389.0 [15.3] 559.0 [22.0]
4YCZ5048 (090)
75.7 [167] 50.8 [112]
45.8 [101] 68.5 [151] 299.2 [659] 240.9 [531]
444.5 [17.5] 698.5 [27.5]
4YCZ5048 (115)
81.6 [180]
46.3 [102]
42.2 [93]
73.5 [162]
301.6 [665] 243.6 [537] 419.1 [16.5] 706.1 [27.8]
4YCZ5060
82.1 [181]
46.3 [102]
43.1 [95] 76.7 [169]
306.9 [676] 248.6 [548] 401.3 [15.8] 711.2 [28.0]
Corner Weights
KG/LBS
SHIPPING
WEIGHT
KG/LBS
UNIT
WEIGHT
KG/LBS
Center Of Gravity
mm[inch]
4YCZ5036 (090)
4YCZ5036 (070)
949.33 [37 - 3/8]
75.41
[2.93]
4YCZ5048 (090)
4YCZ5036 (070)
DDeetteerrmmiinnee UUnniitt CClleeaarraanncceess
