Trane 5TWR4 - Page 29

18-BC117D1-1B-EN 29
PRESSURE CURVES for 5TWR4036A1
LIQUID PRESSURE (PSIG)
OUTDOOR TEMPERATURE (DegreeF) OD ModelCooling@SCFM
5TWR4036A1 1100
SUCTION PRESSURE (PSIG)
OUTDOOR TEMPERATURE (DegreeF)
110
115
120
125
130
135
140
145
150
155
160
165
170
50 60 70 80 90 100 110 120
(1)
170
220
270
320
370
420
470
520
50 60 70 80 90 100 110 120
(1)
(3)
(3)
(5)
(4)
(2)
(2)
INDOOR ENTERING
WETBULBCURVES
TOPTOBOTTOM
71, 67, 63 AND59DEG F.
INDOOR ENTERING
WETBULBCURVES
TOPTOBOTTOM
71, 67, 63 AND59DEG F.
PRESSURE CURVES for 5TWR4042A1
LIQUID PRESSURE (PSIG)
OUTDOOR TEMPERATURE(Degree F) OD ModelCooling @SCFM
5TWR4042A1 1200
SUCTION PRESSURE (PSIG)
OUTDOOR TEMPERATURE(Degree F)
110
115
120
125
130
135
140
145
150
155
160
165
170
50 60 70 80 90 100 110 120
(1)
170
220
270
320
370
420
470
520
50 60 70 80 90 100 110 120
(1)
(3)
(3)
(5)
(4)
(2)
(2)
INDOOR ENTERING
WETBULBCURVES
TOPTOBOTTOM
71, 67, 63 AND59DEG F.
INDOOR ENTERING
WETBULBCURVES
TOPTOBOTTOM
71, 67, 63 AND59DEG F.
