Trane A4AH4 Series - Performance and Electrical Data

18-GF16D1-1B-EN
11
A4AH4E48B1C30A, A4AH4E60B1C30A
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208 – 230 VOLTS
High Med-High
Med † Med-Low Low
0.1 2040 1874 1658 1512 1373
0.2 2008 1846 1622 1476 1333
0.3 1975 1816 1585 1438 1289
0.4 1942 1785 1546 1395 1240
0.5 1909 1751 1506 1349 1187
0.6 1875 1716 1463 1300 1129
0.7 1841 1678 1418 1246 1067
• In downflow applications, airflow must not exceed 1800 cfm due to condensate blowoff.
• Low = Tap 1, Med-Low = Tap 2, Med = Tap 3, Med-High= Tap 4, High = Tap 5
Notes:
• Values are with wet coil, no filter, and no heaters
• CFM Correction for dry coil = Add 3%
• † = Factory Setting
Table 4. Electrical Data
A4AH4E24A1B60A
Heater Model No.
No. of
Circuits/
Phases
240 Volt 208 Volt
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
ProtectionkW BTUH kW BTUH
No Heater 2.8 * 4 15 2.8 * 4 15
BAYHTR1504BRK
BAYHTR1504LUG
1/1
3.8 13100 16.0 24 25 2.9 9800 13.8 21 25
BAYHTR1505BRK
BAYHTR1505LUG
1/1
4.8 16400 20.0 29 30 3.6 12300 17.3 25 25
BAYHTR1508BRK
BAYHTR1508LUG
1/1
7.7 26200 32.0 44 45 5.8 19700 27.7 38 40
BAYHTR1510BRK
BAYHTR1510LUG
1/1
9.6 32800 40.0 54 60 7.2 24600 34.6 47 50
BAYHTR3510LUG
1/3
9.6 32800 23.1 32 35 7.2 24600 20.0 28 30
A4AH4E30A1B30A
Heater Model No.
No. of
Circuits/
Phases
240 Volt 208 Volt
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater 2.8 * 4 15 2.8 * 4 15
BAYHTR1504BRK
BAYHTR1504LUG
1/1
3.8 13100 16.0 24 25 2.9 9800 13.8 21 25
BAYHTR1505BRK
BAYHTR1505LUG
1/1
4.8 16400 20.0 29 30 3.6 12300 17.3 25 25
BAYHTR1508BRK
BAYHTR1508LUG
1/1
7.7 26200 32.0 44 45 5.8 19700 27.7 38 40
BAYHTR1510BRK
BAYHTR1510LUG
1/1
9.6 32800 40.0 54 60 7.2 24600 34.6 47 50
PPeerrffoorrmmaannccee aanndd EElleeccttrriiccaall DDaattaa
