Trane A4AH4 Series - Page 13

18-GF16D1-1B-EN
13
A4AH4E48B1C30A, A4AH4E60B1C30A
BAYHTR1510BRK
BAYHTR1510LUG
1/1 9.6 32800 40.0 58 60 7.2 24600 34.6 51 60
BAYHTR1517BRK-
Circuit 1
(a)
2/1
9.6 32800 40.0 58 60 7.2 24600 34.6 51 60
BAYHTR1517BRK-
Circuit 2
4.8 16400 20.0 25 25 3.6 12300 17.3 22 25
BAYHTR1523BRK-
Circuit 1
2/1
9.6 32800 40.0 58 60 7.2 24600 34.6 51 60
BAYHTR1523BRK-
Circuit 2
9.6 32800 40.0 50 50 7.2 24600 34.6 43 45
BAYHTR1525BRK-
Circuit 1
4/1
6.0 20500 25.0 39 40 4.5 15400 21.6 35 35
BAYHTR1525BRK-
Circuit 2
6.0 20500 25.0 31 35 4.5 15400 21.6 27 30
BAYHTR1525BRK-
Circuit 3
6.0 20500 25.0 31 35 4.5 15400 21.6 27 30
BAYHTR1525BRK-
Circuit 4
6.0 20500 25.0 31 35 4.5 15400 21.6 27 30
BAYHTR3510LUG
1/3 9.6 32800 23.1 36 40 7.2 24600 20.0 32 35
BAYHTR3517LUG
1/3 14.4 49100 34.6 50 50 10.8 36900 30.0 44 45
BAYHTR1517BRK
with single circuit
power source kit
BAYSPEKT201A
1/1
14.4 49100 60.0 83 90 10.8 36900 51.9 73 80
BAYHTR1523BRK
with single circuit
power source kit
BAYSPEKT201A
1/1 19.2 65500 80.0 108 110 14.4 49100 69.2 94 100
(a)
MCA and MOP for circuit 1 contains the motor amps.
Notes:
• * = Motor Amps
PPeerrffoorrmmaannccee aanndd EElleeccttrriiccaall DDaattaa
